LED Backlight, there are 7 colors, which can be switched freely: press the button for 3 seconds to switch the backlight color when the odometer is in the ODO state.
A high cost performance meter that contains four functions, tachometer, speedometer, odometer, fuel gauge.
Connection method: Black-positive wire; Green-negative wire; Black&red-Extreme speed signal line; Blue&white-Oil signal.
Material: aluminium alloy.
This meter is very practical and cool that can be adjusted by seven different colors. Work with any motorcycle with 12V batteries
Maximum display 10,000 rpm lay is 199. Can be set to km KM/H and miles MPH
Voltage: DC 12V
Oil gauge:there are two lines (8-98 Euro) and three-line oil meter (33-565 Euro)
Odometer:there are two kinds of cumulative ODO and zero return TRIP, the default display ODO Switching between KM/H and MPH: Press and hold the button without releasing and then open the switch. The screen displays P0000. At this time, the bit 0 flashes.Long press to jump to ten digits 0 flashes, short ten ten digits display is 1, then long press to jump to hundred digits flashing, short press 6 hundreds of digits to display 6.Press and hold for thousands of digits, and press 6 times to display 6 digits. At this time, the screen displays 00466, which means that 46.6HZ corresponds to 60KM/H.Short press to skip (this item is not set), then the screen displays 1001, 1001 means KM/H, if you want to switch to MPH Long press the single digit flashing, long press to switch to 1002, indicating that it has been set to MPH. Short press to jump to the next item.
Speed cylinder number setting:Connect to the above, short press the screen to display 2002, indicating that this time is 2 cylinders (166HZ corresponds to 10*1000RPM/MIN), short press to skip long press and flash, then press one digit 2Switch to 4, indicating that it has been switched to 4 cylinders (333HZ corresponds to 10*1000RPM/MIN), short press to jump to the next item.
1 X Multifunctional Modification Instrumentation
